News New Case Study for Role in the Design of an Effective Sphere Spectrometer System

New Case Study for Role in the Design of an Effective Sphere Spectrometer System


Environmental Control System for PhotonicsAir Innovations – the leader in custom environmental control solutions for temperature, humidity, filtration, and pressure – announced the availability of a new case study on an international manufacturer to the photonics industry for which the company helped design a custom thermoelectric-based control system that could effectively rate the lumens in light emitting diode bulbs.

The photonics manufacturers builds imaging devices in aerospace, medical, optics, and a variety of other industries and required an ECU that could be momentarily turned off five seconds and then come back on instantly. Air Innovations designed a solution of automatic diverter dampers so the ECU could operate continuously, but the supply air to the test chamber could be suspended for five seconds.The custom temperature-control system can maintain a diverse number of settings within a wide range of temperatures to meet the client’s specific needs.

Additional key specifications were temperature control to accommodate various LED test ranging from 5 – 50 Deg C (+/- 0.5 Deg C), air flow range of 30-400 CFM , and internal heat load from 0 to 900 watts. The system was delivered to Brazil, so international power and codes also needed to be considered for the sphere spectrometer system.

sphere for measuring lumens  Read the full version of this environmental control case study.
